Bulkgridscale Energy Storage 200A Brand 1
Bulkgridscale Energy Storage 200A Brand 2
Bulkgridscale Energy Storage 200A Brand 1
Bulkgridscale Energy Storage 200A Brand 2

Bulkgridscale Energy Storage 200A Brand

Weight:
75kg
Maximum Charge Voltage:
58.8Vdc
Max. Continuous Discharge Current:
200A
Energy storage:
6.5kWh
Discharge Cut-off Voltage:
37Vdc
Inquiry

Company Advantages

· gridscale energy storage has met the industrial design requirements.

· We implement quality control system to ensure products without defects.

· This product is over and above our rival's product, and yet we're able to sell it at the same price.

Product Parameters
General Characteristics
Mechanical Specifications

Part Number

GTEM-48V6500-G

Energy storage

6.5kWh

Nominal Voltage

48Vdc

Nominal Capacity

130Ah

Maximum Charge Voltage

58.8Vdc

Discharge Cut-off Voltage

37Vdc

ESR/AC @1KHz 50% SOC

<15mΩ

Max. Continuous Charge Current

200A

Max. Continuous Discharge Current

200A

Absolute Peak Current 3s

300A

Discharge Temperature

-20℃~+60℃

Charge Temperature

0℃~+55℃

Cooling Method

Natural cooling

Operating Humidity

0~90% RH Non-condensing

Cells Self-discharge Rate

2% per month

Recommended Depth of Discharge

≤90%

Maximum Depth of Discharge

100%

Shell Material

Metal & ABS plastic

Monitoring Data

System voltage,current, temperature,SOC,SOH,cycle,

cell’s voltage

Indicator light display

Capacity %

Environmental Protection

IP65

Storage Conditions

-20℃~+40℃

25% ~ 95%RH

SOC>30%,one full charge needed per two months

Weight

75kg

Dimensions(WxDxH)

940x400x252(mm)

Mount Options

On floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)
1 (10)
2 (9)
2 (9)
3 (7)
3 (7)
4 (7)
4 (7)
5 (8)
5 (8)
6 (11)
6 (11)
7 (6)
7 (6)

Download


Company Features

· is an internationally renowned leading enterprise committed to gridscale energy storage production.

· First-class equipment, production technology and business management guarantee the first-class quality of

· We've developed a holistic plan that goes beyond conservation and aims to deliver value to all touch points for customers, suppliers, and our communities while ensuring a sustainable future for Check now!


Product Details

More details of gridscale energy storage are shown as follows.

Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
