Capacitor Bank Panel 42Vdc

Series:
Capess Series
Part Number:
GTEM-48V7500-E
Maximum Charge Voltage:
58Vdc
Max. Continuous Charge Current:
100A
Discharge Cut-off Voltage:
42Vdc
Inquiry

Product Parameters
General Characteristics
Mechanical Specifications

Part Number

GTEM-48V7500-E

Energy storage

7.5kWh

Nominal Voltage

51.8Vdc

Maximum Charge Voltage

58Vdc

Discharge Cut-off Voltage

42Vdc

ESR/AC @1KHz 50% SOC

<10mΩ

Max. Continuous Charge Current

100A

Max. Continuous Discharge Current

100A

Cooling Method

Natural

Cells Self-discharge Rate

2% per month

Projected Cycle Life ( 25℃)

20,000 times

Recommended Depth of Discharge

≤90%

Maximum Depth of Discharge

100%

Shell Material

Metal & ABS plastic

Monitoring Data

System voltage, current, temperature, SOC, SOH, cycle, cell's voltage

Series Connection

Not allowed

Parallel Connection

Up to 16 sets

Series-Parallel Connection

Not allowed

Weight

72kg

Dimensions(WxDxH)

475x685x177(mm)

Mount Options

On floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)
1 (10)
2 (9)
2 (9)
3 (7)
3 (7)
4 (7)
4 (7)
5 (8)
5 (8)
6 (11)
6 (11)
7 (6)
7 (6)

Download


Company Advantages

· capacitor bank panel is designed by renowned designers in the field.

· The product excels in quality, performance, function, durability, etc.

· spares no effort to help solve customers' problem.


Company Features

· Highly committed to the manufacturing of capacitor bank panel for years, is developing stronger and more competitive now.

· Utilizing technological innovation will drive to develop more rapidly.

· research is unique and innovative and our capacitor bank panel are of excellent quality. Inquiry!


Application of the Product

capacitor bank panel can be used in different industries to meet the needs of customers.

Based on customers' specific situations and needs, provides comprehensive and reasonable solutions.

Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
