Product details of the panel capacitor bank
Product Information
The design of panel capacitor bank is something nice to have. The competitive advantages of this product are as follows: long service life, good performance and excellent quality. The product is popular in the market, meeting the requirements of customers.
Part Number | GTEF-205V10K-S | GTEF-307V15K-S | GTEF-410V20K-S | GTEF-512V25K-S | GTEF-614V30K-S |
Energy storage | 10kWh | 15kWh | 20kWh | 25kWh | 30kWh |
Number of series modules | 2 | 3 | 4 | 5 | 6 |
Nominal Voltage | 204.8Vd.c | 307.2Vd.c | 409.6Vd.c | 512Vd.c | 614.4Vd.c |
Maximum Charge Voltage | 230.4Vd.c | 345.6Vd.c | 460.8Vd.c | 576Vd.c | 691.2Vd.c |
Discharge Cut-off Voltage | 179.2Vd.c | 268.8Vd.c | 358.4Vd.c | 448Vd.c | 537.6Vd.c |
ESR/AC @1KHz 50% SOC | <100mΩ | <140mΩ | <180mΩ | <220mΩ | <260mΩ |
Max. Continuous Power | 5kW | 7.5kW | 10kW | 12.5kW | 15kW |
Weight | 90kg | 130kg | 170kg | 210kg | 250kg |
Max. Continuous Charge Current | 25A | 25A | 25A | 25A | 25A |
Max. Continuous Discharge Current | 25A | 25A | 25A | 25A | 25A |
Nominal Capacity | 52Ah | 52Ah | 52Ah | 52Ah | 52Ah |
Communication Way | CAN | CAN | CAN | CAN | CAN |
Monitoring Data | System voltage, current, temperature, SOC, SOH, cell voltage. | System voltage, current, temperature, SOC, SOH, cell voltage. | System voltage, current, temperature, SOC, SOH, cell voltage. | System voltage, current, temperature, SOC, SOH, cell voltage. | System voltage, current, temperature, SOC, SOH, cell voltage. |
Projected Cycle Life ( 25℃) | 10000 times(70%EOL) | 10000 times(70%EOL) | 10000 times(70%EOL) | 10000 times(70%EOL) | 10000 times(70%EOL) |
Recommended Depth of Discharge | ≤90% | ≤90% | ≤90% | ≤90% | ≤90% |
Maximum Depth of Discharge | 100% | 100% | 100% | 100% | 100% |
Environmental Protection | IP 20 Indoor | IP 20 Indoor | IP 20 Indoor | IP 20 Indoor | IP 20 Indoor |
Shell Material | Metal | Metal | Metal | Metal | Metal |
Parallel Connection optional | Not allowed | Not allowed | Not allowed | Not allowed | Not allowed |
Company Feature
• has a large and complete sales network. Some of the products like nbsp;are exported overseas and are very popular in the foreign market.
• location enjoys traffic convenience with multiple traffic lines passing through. This is conducive to the outward transportation and is the guarantee of timely supply of products.
• With a sound service system, is committed to sincerely providing excellent services including pre-sale, in-sale, and after-sale. We meet users' needs and improve the user experience.
have quality assurance and favorable price. Why are you still hesitating? Just contact us to order!
Welcome, Shanghai Green Tech (GTCAP) is a supercapacitor battery manufacturer and energy storage solutions provider,
offering OEM, ODM and customized energy storage solutions for customers.
