Deep Cycle Boat Battery 204.8Vd.c Company

Series:

EF Series

Part Number:

GTEF-205V10K-S

Nominal Voltage:

204.8Vd.c

Max. Continuous Charge Current:

25A

Discharge Cut-off Voltage:

179.2Vd.c

Inquiry

more products

Send your inquiry

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEF-205V10K-S	GTEF-307V15K-S	GTEF-410V20K-S	GTEF-512V25K-S	GTEF-614V30K-S
Energy storage	10kWh	15kWh	20kWh	25kWh	30kWh
Number of series modules	2	3	4	5	6
Nominal Voltage	204.8Vd.c	307.2Vd.c	409.6Vd.c	512Vd.c	614.4Vd.c
Maximum Charge Voltage	230.4Vd.c	345.6Vd.c	460.8Vd.c	576Vd.c	691.2Vd.c
Discharge Cut-off Voltage	179.2Vd.c	268.8Vd.c	358.4Vd.c	448Vd.c	537.6Vd.c
ESR/AC @1KHz 50% SOC	＜100mΩ	＜140mΩ	＜180mΩ	＜220mΩ	＜260mΩ
Max. Continuous Power	5kW	7.5kW	10kW	12.5kW	15kW
Weight	90kg	130kg	170kg	210kg	250kg
Max. Continuous Charge Current	25A	25A	25A	25A	25A
Max. Continuous Discharge Current	25A	25A	25A	25A	25A
Nominal Capacity	52Ah	52Ah	52Ah	52Ah	52Ah
Communication Way	CAN	CAN	CAN	CAN	CAN
Monitoring Data	System voltage, current, temperature, SOC, SOH, cell voltage.	System voltage, current, temperature, SOC, SOH, cell voltage.	System voltage, current, temperature, SOC, SOH, cell voltage.	System voltage, current, temperature, SOC, SOH, cell voltage.	System voltage, current, temperature, SOC, SOH, cell voltage.
Projected Cycle Life ( 25℃)	10000 times(70%EOL)	10000 times(70%EOL)	10000 times(70%EOL)	10000 times(70%EOL)	10000 times(70%EOL)
Recommended Depth of Discharge	≤90%	≤90%	≤90%	≤90%	≤90%
Maximum Depth of Discharge	100%	100%	100%	100%	100%
Environmental Protection	IP 20 Indoor	IP 20 Indoor	IP 20 Indoor	IP 20 Indoor	IP 20 Indoor
Shell Material	Metal	Metal	Metal	Metal	Metal
Parallel Connection optional	If connect in Parallel connection, pls inform before order confirmation	If connect in Parallel connection, pls inform before order confirmation	If connect in Parallel connection, pls inform before order confirmation	If connect in Parallel connection, pls inform before order confirmation	If connect in Parallel connection, pls inform before order confirmation

Company Advantages

· The production of deep cycle boat battery strictly complies with ISO standard manufacturing processes.

· The product is reliable with consistent performance.

· Strong production strength of shows the ability to be your first choice for cooperation.

Company Features

· is known for strong ability in manufacturing market-oriented deep cycle boat battery. We are considered as an expert in the China market.

· has advanced production equipment, excellent manufacturing technology and complete testing methods.

· We will maintain the quality, integrity, and respect for our values. It's all about producing world-class products designed to improve our customers' business. Inquire now!

Application of the Product

deep cycle boat battery is widely used in the industry and is widely recognized by customers.

insists on providing customers with comprehensive solutions based on their actual needs, so as to help them achieve long-term success.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
