Deep Cycle Marine Battery 25Amade in China

Series:
EF Series
Part Number:
GTEF-205V10K-S
Maximum Charge Voltage:
230.4Vd.c
Max. Continuous Discharge Current:
25A
Max. Continuous Charge Current:
25A
Inquiry

Product details of the deep cycle marine battery


Product Information

The production equipment of deep cycle marine battery is advanced and meets the requirements of international standards. The product guarantees superior quality, stable performance and long service life. will maintain the efficient operation of the organization and management system under normal conditions.

Product Parameters
General Characteristics
Mechanical Specifications
Part Number GTEF-205V10K-S GTEF-307V15K-S GTEF-410V20K-S GTEF-512V25K-S GTEF-614V30K-S
Energy storage 10kWh 15kWh 20kWh 25kWh 30kWh
Number of series modules 2 3 4 5 6
Nominal Voltage 204.8Vd.c 307.2Vd.c 409.6Vd.c 512Vd.c 614.4Vd.c
Maximum Charge Voltage 230.4Vd.c 345.6Vd.c 460.8Vd.c 576Vd.c 691.2Vd.c
Discharge Cut-off Voltage 179.2Vd.c 268.8Vd.c 358.4Vd.c 448Vd.c 537.6Vd.c
ESR/AC @1KHz 50% SOC <100mΩ <140mΩ <180mΩ <220mΩ <260mΩ
Max. Continuous Power 5kW 7.5kW 10kW 12.5kW 15kW
Weight 90kg 130kg 170kg 210kg 250kg
Max. Continuous Charge Current 25A 25A 25A 25A 25A
Max. Continuous Discharge Current 25A 25A 25A 25A 25A
Nominal Capacity 52Ah 52Ah 52Ah 52Ah 52Ah
Communication Way CAN CAN CAN CAN CAN
Monitoring Data System voltage, current, temperature, SOC, SOH, cell voltage.
Projected Cycle Life ( 25℃) 10000 times(70%EOL)
Recommended Depth of Discharge ≤90% ≤90% ≤90% ≤90% ≤90%
Maximum Depth of Discharge 100% 100% 100% 100% 100%
Environmental Protection IP 20 Indoor IP 20 Indoor IP 20 Indoor IP 20 Indoor IP 20 Indoor
Shell Material Metal Metal Metal Metal Metal
Parallel Connection optional

If connect in Parallel connection, pls inform before order confirmation
