Deep Cycle Marine Battery High Quality for Agriculture

Product details of the deep cycle marine battery

Quick Overview

deep cycle marine battery is designed perfectly and made with best materials. The product has the guarantee of our know-how and internationally-certified quality. The deep cycle marine battery developed by is widely used in industry. The customers speak highly of the quality of deep cycle marine battery made by

Product Information

will present you the details of deep cycle marine battery in the following section.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEF-48V5000-E
Energy storage	5.0kWh
Nominal Voltage	48Vdc
Maximum Charge Voltage	58Vdc
Discharge Cut-off Voltage	37.8Vdc
ESR/AC @1KHz 50% SOC	<15mΩ
Max. Continuous Charge Current	100A
Max. Continuous Discharge Current	100A
Peak Current	208A
Cooling Method	Natural
Cells Self-discharge Rate	2% per month
Projected Cycle Life ( 25℃)	20,000 times
Recommended Depth of Discharge	≤90%
Maximum Depth of Discharge	100%
Shell Material	Metal & ABS plastic
Monitoring Data	SOC,voltage,current, temperature
Series Connection	Not allowed
Parallel Connection	Up to 10sets
Series-Parallel Connection	Not allowed

Weight	62kg
Dimensions(WxDxH)	475x665x177(mm)
Mount Options	On floor

Certificate Options

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Company Introduction

As a enterprise, mainly deals with the research and development, production and sales of follows the business philosophy of 'positive and aspirant, innovative and pioneering'. And we adhere to our enterprise spirit, to be passionate, responsible and innovative. Based on that, we strive to improve our core competitiveness. With the purpose of realizing the optimization of enterprise profits and social benefits, we insist on developing the business in a systematic way, which is conducive to corporate sustainable development. We are dedicated to becoming a modern enterprise with a worldwide reputation. core team members have rich industry experience and master the core industry technology. They are the backbone of enterprise development. Based on customers' specific situations and needs, provides comprehensive and reasonable solutions.
Don't forget to contact us to order.
