graphene battery electric car is produced adopting new environmentally-friendly materials. The product is quality certified for long life. has years of production experience for graphene battery electric car.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEG-23V4180-F
Energy storage	4.18kWh
Nominal Capacity	182Ah
Nominal Voltage	23Vdc
Absolute Maximum Voltage	28Vdc
Cut-off Voltage (discharging)	18Vdc
Configuration	10S13P
Pack resistance	< 10 mΩ
Continuous Charge Current	150A
Continuous Discharge Current	150A
Peak Discharge Current	300A
Recommended Depth of Discharge	90%
Maximum Depth of Discharge	100%
Cooling	Natural cooling
Ingress Protection	IP55
Storage Humidity	25% ~ 95%RH
Operating Humidity	0 – 90% RH
Storage Temperature	-20℃~40 ℃

Weight	225kg
Dimensions(WxDxH)	650195600mm
Mount Options	Wall/ floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Advantage

• Our sales network is expanding into a nationwide network with the city as the center. At the same time, our products are exported to Central Asia, Eastern Europe, Northern Europe and other regions, so that product share in the domestic and international market is increasing year by year.
• Our company wholeheartedly provides customers with advanced, high quality and cost-effective services.
• has advantageous conditions for product delivery. Nearby there is a prosperous market, developed communication, and traffic convenience.
• Rich in production experience and mature in processing technology, has developed into an excellent enterprise after years of flourishing.
Thanks for visiting. will provide various product information and help you further understand the industry.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
