High End Capacitor Bank Panel 230.4Vd.c Company 1

High End Capacitor Bank Panel 230.4Vd.c Company 2

High End Capacitor Bank Panel 230.4Vd.c Company 3

High End Capacitor Bank Panel 230.4Vd.c Company 4

High End Capacitor Bank Panel 230.4Vd.c Company

Series:

EF Series

Maximum Charge Voltage:

230.4Vd.c

Max. Continuous Charge Current:

25A

Energy storage:

10kWh

Dimensions(WxDxH):

480x520x160(mm)

Inquiry

more products

Capwall

Graphene Supercapacitor Battery

Solid-state Supercapacitor Battery

Hybrid Inverter

Complete Residential Solar Power Systems

Send your inquiry

Product details of the capacitor bank panel

Product Information

With the assistance of a team of innovative and experienced designers, capacitor bank panel is given a wide variety of design styles. We meet the quality standards as per the customer demands. As a dominant capacitor bank panel supplier, focus on its customer service.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEF-205V10K-S	GTEF-307V15K-S	GTEF-410V20K-S	GTEF-512V25K-S	GTEF-614V30K-S
Energy storage	10kWh	15kWh	20kWh	25kWh	30kWh
Number of series modules	2	3	4	5	6
Nominal Voltage	204.8Vd.c	307.2Vd.c	409.6Vd.c	512Vd.c	614.4Vd.c
Maximum Charge Voltage	230.4Vd.c	345.6Vd.c	460.8Vd.c	576Vd.c	691.2Vd.c
Discharge Cut-off Voltage	179.2Vd.c	268.8Vd.c	358.4Vd.c	448Vd.c	537.6Vd.c
ESR/AC @1KHz 50% SOC	＜100mΩ	＜140mΩ	＜180mΩ	＜220mΩ	＜260mΩ
Max. Continuous Power	5kW	7.5kW	10kW	12.5kW	15kW
Weight	90kg	130kg	170kg	210kg	250kg
Max. Continuous Charge Current	25A	25A	25A	25A	25A
Max. Continuous Discharge Current	25A	25A	25A	25A	25A
Nominal Capacity	52Ah	52Ah	52Ah	52Ah	52Ah
Communication Way	CAN	CAN	CAN	CAN	CAN
Monitoring Data	System voltage, current, temperature, SOC, SOH, cell voltage.	System voltage, current, temperature, SOC, SOH, cell voltage.	System voltage, current, temperature, SOC, SOH, cell voltage.	System voltage, current, temperature, SOC, SOH, cell voltage.	System voltage, current, temperature, SOC, SOH, cell voltage.
Projected Cycle Life ( 25℃)	10000 times(70%EOL)	10000 times(70%EOL)	10000 times(70%EOL)	10000 times(70%EOL)	10000 times(70%EOL)
Recommended Depth of Discharge	≤90%	≤90%	≤90%	≤90%	≤90%
Maximum Depth of Discharge	100%	100%	100%	100%	100%
Environmental Protection	IP 20 Indoor	IP 20 Indoor	IP 20 Indoor	IP 20 Indoor	IP 20 Indoor
Shell Material	Metal	Metal	Metal	Metal	Metal
Parallel Connection optional	Not allowed	Not allowed	Not allowed	Not allowed	Not allowed

Company Advantage

• employees are mainly composed of experienced experts and young people with strong professional ability. They have a good team spirit and ensure the efficient operation and rapid development of the enterprise.
• With the highest sincerity and the best attitude, strives to provide consumers with satisfactory services in line with their real needs.
• products are not only sold well in China but also exported to Southeast Asia, Africa, and other foreign countries. They are highly praised by local consumers.
• Good geographic location, excellent traffic conditions, and telecommunications make contribution to sustainable development.
is specializing in the production of various The products are safe and reliable with high cost performance. We sincerely invite domestic and foreign buyers to place orders. And we are also looking forward to establishing long-term partnerships with us.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
