New Arrival Capacitor Bank Panel Manufacture

Nominal Voltage:
204.8Vd.c
Maximum Charge Voltage:
230.4Vd.c
Max. Continuous Discharge Current:
25A
Energy storage:
10kWh
Discharge Cut-off Voltage:
179.2Vd.c
Inquiry
Send your inquiry

Company Advantages

· The innovative design of capacitor bank panel makes it more competitive.

· Its user-friendly performance is ensured under any circumstance.

· With a 'customer first' attitude, maintains good communication with customers.

Product Parameters
General Characteristics
Mechanical Specifications
Part Number GTEF-205V10K-S GTEF-307V15K-S GTEF-410V20K-S GTEF-512V25K-S GTEF-614V30K-S
Energy storage 10kWh 15kWh 20kWh 25kWh 30kWh
Number of series modules 2 3 4 5 6
Nominal Voltage 204.8Vd.c 307.2Vd.c 409.6Vd.c 512Vd.c 614.4Vd.c
Maximum Charge Voltage 230.4Vd.c 345.6Vd.c 460.8Vd.c 576Vd.c 691.2Vd.c
Discharge Cut-off Voltage 179.2Vd.c 268.8Vd.c 358.4Vd.c 448Vd.c 537.6Vd.c
ESR/AC @1KHz 50% SOC <100mΩ <140mΩ <180mΩ <220mΩ <260mΩ
Max. Continuous Power 5kW 7.5kW 10kW 12.5kW 15kW
Weight 90kg 130kg 170kg 210kg 250kg
Max. Continuous Charge Current 25A 25A 25A 25A 25A
Max. Continuous Discharge Current 25A 25A 25A 25A 25A
Nominal Capacity 52Ah 52Ah 52Ah 52Ah 52Ah
Communication Way CAN CAN CAN CAN CAN
Monitoring Data System voltage, current, temperature, SOC, SOH, cell voltage.
Projected Cycle Life ( 25℃) 10000 times(70%EOL)
Recommended Depth of Discharge ≤90% ≤90% ≤90% ≤90% ≤90%
Maximum Depth of Discharge 100% 100% 100% 100% 100%
Environmental Protection IP 20 Indoor IP 20 Indoor IP 20 Indoor IP 20 Indoor IP 20 Indoor
Shell Material Metal Metal Metal Metal Metal
Parallel Connection optional

If connect in Parallel connection, pls inform before order confirmation


Company Features

· is among the top domestic and foreign producers in China.

· strengthens the technology of research and development of capacitor bank panel which satisfies the needs of different customers.

· Integrity is our business philosophy. We work on a transparent schedule and maintain an in-depth collaboration process to ensure that we meet the specific needs of each client. Get info!


Product Details

Next, the details of capacitor bank panel are shown for you.


Application of the Product

capacitor bank panel is widely applicable in the industry.

We will communicate with our customers to understand their situations and provide them with effective solutions.


Product Comparison

Compared with similar products, the capacitor bank panel of is more strict in the selection of raw materials. The specific aspects are as follows.

Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
