The raw materials of household solar battery cost are meticulously selected to make sure each of them works perfectly, through which the quality of the product can be ensured from the source. Our QC team implements a strict quality control system and perfect monitor method. The product has won wide recognition from customers and a wide prospect of application.

Product Description

Compared with similar products, household solar battery cost is more advantageous in the following aspects.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-24V3200-E
Energy storage	3.2kWh
Nominal Voltage	24Vdc
Maximum Charge Voltage	29Vdc
Discharge Cut-off Voltage	20Vdc
ESR/AC @1KHz 50% SOC	<15Ω
Max. Continuous Charge Current	40A
Max. Continuous Discharge Current	40A
Cells Self-discharge Rate	2% per month
Projected Cycle Life ( 25℃)	20,000 times
*Round Trip Efficiency1**	96%
Recommended Depth of Discharge	≤90%
Maximum Depth of Discharge	100%
Cooling Method	Natural
Shell Material	Metal & ABS plastic
Monitoring Data	System voltage,current, temperature,SOC,SOH,cycle,cell`s voltage

Weight	20kg
Dimensions(WxDxH)	347x224x200mm
Mount Options	Wall/ floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Information

Being superior in producing high quality household solar battery cost, has become a star brand in the industry. has a team of specialists and manufacturing engineers. establishes a sensible management system for the long-term development of its customers. Ask online!
We look forward to working with you to move towards a more brilliant era.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
