Types of Capacitor Bank EF Series

Series:

EF Series

Nominal Voltage:

204.8Vd.c

Max. Continuous Charge Current:

25A

Discharge Cut-off Voltage:

179.2Vd.c

Dimensions(WxDxH):

480x520x160(mm)

Inquiry

Product details of the types of capacitor bank

Quick Overview

types of capacitor bank adopts superior raw materials, which is thoroughly checked by our factory. The product is of top quality and has reliable performance at competitive prices. Always putting customer first in the first place is essential for the development of

Product Introduction

will show you product's specific details below.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEF-205V10K-S	GTEF-307V15K-S	GTEF-410V20K-S	GTEF-512V25K-S	GTEF-614V30K-S
Energy storage	10kWh	15kWh	20kWh	25kWh	30kWh
Number of series modules	2	3	4	5	6
Nominal Voltage	204.8Vd.c	307.2Vd.c	409.6Vd.c	512Vd.c	614.4Vd.c
Maximum Charge Voltage	230.4Vd.c	345.6Vd.c	460.8Vd.c	576Vd.c	691.2Vd.c
Discharge Cut-off Voltage	179.2Vd.c	268.8Vd.c	358.4Vd.c	448Vd.c	537.6Vd.c
ESR/AC @1KHz 50% SOC	＜100mΩ	＜140mΩ	＜180mΩ	＜220mΩ	＜260mΩ
Max. Continuous Power	5kW	7.5kW	10kW	12.5kW	15kW
Weight	90kg	130kg	170kg	210kg	250kg
Max. Continuous Charge Current	25A	25A	25A	25A	25A
Max. Continuous Discharge Current	25A	25A	25A	25A	25A
Nominal Capacity	52Ah	52Ah	52Ah	52Ah	52Ah
Communication Way	CAN	CAN	CAN	CAN	CAN
Monitoring Data	System voltage, current, temperature, SOC, SOH, cell voltage.	System voltage, current, temperature, SOC, SOH, cell voltage.	System voltage, current, temperature, SOC, SOH, cell voltage.	System voltage, current, temperature, SOC, SOH, cell voltage.	System voltage, current, temperature, SOC, SOH, cell voltage.
Projected Cycle Life ( 25℃)	10000 times(70%EOL)	10000 times(70%EOL)	10000 times(70%EOL)	10000 times(70%EOL)	10000 times(70%EOL)
Recommended Depth of Discharge	≤90%	≤90%	≤90%	≤90%	≤90%
Maximum Depth of Discharge	100%	100%	100%	100%	100%
Environmental Protection	IP 20 Indoor	IP 20 Indoor	IP 20 Indoor	IP 20 Indoor	IP 20 Indoor
Shell Material	Metal	Metal	Metal	Metal	Metal
Parallel Connection optional	If connect in Parallel connection, pls inform before order confirmation	If connect in Parallel connection, pls inform before order confirmation	If connect in Parallel connection, pls inform before order confirmation	If connect in Parallel connection, pls inform before order confirmation	If connect in Parallel connection, pls inform before order confirmation

Company Advantages

Located in is a comprehensive enterprise integrating the production, processing and sales of runs a high-quality logistics management system to achieve efficient transportation of products. Besides, we run a comprehensive pre-sales, sales and after-sales service system to solve various problems in time for customers. Welcome to discuss business cooperation with us!

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
