Battery Energy Storage EM Series Brand 200A

Company Advantages

· battery energy storage boasts reasonable design compared to traditional type. .

· The product has excellent performance, stable and reliable quality.

· We greatly value every detail when manufacturing battery energy storage.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-48V4500-G
Energy storage	4.5kWh
Nominal Voltage	48Vdc
Nominal Capacity	130Ah
Maximum Charge Voltage	58.8Vdc
Discharge Cut-off Voltage	40Vdc
ESR/AC @1KHz 50% SOC	<30mΩ
Max. Continuous Charge Current	200A
Max. Continuous Discharge Current	200A
Absolute Peak Current 3s	400A
Discharge Temperature	-20℃~+60℃
Charge Temperature	0℃~+55℃
Cooling Method	Natural cooling
Operating Humidity	0~90% RH Non-condensing
Cells Self-discharge Rate	2% per month
Projected Cycle Life ( 25℃)	20,000 times
Recommended Depth of Discharge	≤90%
Maximum Depth of Discharge	100%
Shell Material	Metal & ABS plastic
Monitoring Data	Module voltage,SOC
Indicator light display	Capacity %
Environmental Protection	IP65
Storage Conditions	-20℃~+40℃ 25% ~ 95%RH SOC>30%，one full charge needed per two months

Weight	55kg
Dimensions(WxDxH)	720x355x252(mm)
Mount Options	On floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Features

· has been recognized as a forefront enterprise in battery energy storage industry.

· has fully established relatively complete technology system to produce battery energy storage. By developing new technological methods, manufactures battery energy storage to be a more competitive product.

· We think highly of sustainability. We implement year-round sustainability initiatives. And we operate businesses safely, using a renewable resource that must be managed responsibly.

Product Details

battery energy storage's specific details in are mainly reflected in the following aspects.

Application of the Product

battery energy storage of is widely used and has a wide range of applications.

With professional engineers and technicians in our company, is able to provide one-stop and comprehensive solutions for customers.
