Battery Energy Storage System 125 F Company

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTSM-48V165FUS
Nominal capacitance	125 F
Capacitance tolerance	-10%~~+20%
Rated voltage	48V
Maximum absolute voltage	51V
ESR, DC	5 mΩ
Maximum continuous current (ΔT=40℃)	100 A
Maximum peak current, 1 sec.	2,275 A
Maximum leakage current (after 72hrs @ 25℃)	5.2 mA
Operating temperature range (Cell case temperature)	-40℃ to +65℃
Storage temperature range(Storage uncharged)	-40℃ to +70℃
Power terminals	M8 Screw Hole
Negative Terminal	M10 Screw Hole
Recommended torque - terminal	20/30 Nm
Vibration specification	SAE J2380 ISO16750-2, T14
Shock specification	SAE J2464
Colling	Natural Convection

Weight	20kg
Environmental protection	IP65
Internal temperature sensor	NTC Thermistor
Cell voltage monitoring	Overvoltage Alarm

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Advantages

· battery energy storage system is fabricated from optimum quality raw materials with superior strength and durability.

· A strict quality check system has been built to ensure its quality.

· With solid technical strength, has strong capability of

Company Features

· has been manufacturing and supplying high quality battery energy storage system for many years.

· Our employees excel in their respective fields. Due to comprehensive training and good development possibilities, many of them are highly specialized, with outstanding qualifications and experience.

· Thoroughly implementing innovation-driven development strategy will absolutely boost the popularity of battery energy storage system. Inquire online!

Application of the Product

battery energy storage system of can be used in different industries to meet the needs of customers in different fields.

is able to meet customers' needs to the greatest extent by providing customers with one-stop and high-quality solutions.
