Product details of the battery energy storage system
Product Description
The technical production standard of battery energy storage system far exceeds the market average. Its quality and performance are taken into account strictly. The product is gaining larger market clout and wider application.
Part Number |
GTSM-48V165FUS |
Nominal capacitance |
125 F |
Capacitance tolerance |
-10%~~+20% |
Rated voltage |
48V |
Maximum absolute voltage |
51V |
ESR, DC |
5 mΩ |
Maximum continuous current (ΔT=40℃) |
100 A |
Maximum peak current, 1 sec. |
2,275 A |
Maximum leakage current (after 72hrs @ 25℃) |
5.2 mA |
Operating temperature range (Cell case temperature) |
-40℃ to +65℃ |
Storage temperature range(Storage uncharged) |
-40℃ to +70℃ |
Power terminals |
M8 Screw Hole |
Negative Terminal |
M10 Screw Hole |
Recommended torque - terminal |
20/30 Nm |
Vibration specification |
SAE J2380 ISO16750-2, T14 |
Shock specification |
SAE J2464 |
Colling |
Natural Convection |
Weight |
20kg |
Environmental protection |
IP65 |
Internal temperature sensor |
NTC Thermistor |
Cell voltage monitoring |
Overvoltage Alarm |
Compatible Protocol: CAN, RS485
