Best Deep Cycle Marine Battery 291.6Vdc

Product details of the best deep cycle marine battery

Quick Detail

The design and production techniques of best deep cycle marine battery are competitive in the industry. The product quality is assured after hundreds of testings. Our best deep cycle marine battery meets the needs of multiple industries and fields. best deep cycle marine battery is produced from design to production which are under exquisite management to ensure the quality.

Product Description

Our best deep cycle marine battery has a certain share in the market because of the following characteristics.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-400V14.4K-R
Energy storage	14.4kWh
Nominal Voltage	400Vdc
Maximum Charge Voltage	453.6Vdc
Discharge Cut-off Voltage	291.6Vdc
ESR/AC @1KHz 50% SOC	<200mΩ
Max. Continuous Charge Current	30A
Max. Continuous Discharge Current	30A
Round Trip Efficiency*1	96%
Projected Cycle Life ( 25℃)	20,000 times
Recommended Depth of Discharge	≤90%
Maximum Depth of Discharge	100%
Cooling Method	Natural
Shell Material	Metal & ABS plastic
Monitoring Data	System voltage,current, temperature, SOC,SOH,cycle,cell’s voltage
Parallel connection optional	Up to 4sets (400V 60KWh)
Communication	CAN, RS485

Weight	165kg±5kg
Dimensions(WxDxH)	520x732x653(mm)
Mount Options	On floor

Certificate Options

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Company Information

Years of best deep cycle marine battery production experience, as well as technology improvements, has made become one of the most powerful manufacturers. The factory is located in an advantageous place where it is the combination part of the new urban area and old urban area and is not far away from ports and major highways. This location benefits not the factory but also customers. Our company makes environmental protection a top priority. In our production, dust and liquid waste are collected and incinerated to ensure that they are not discharged into the environment.
We only produce high-quality products. Welcome customers to contact customer service staff for consultation!
