Brand Battery Energy Storage Supplier

Series:

EM Series

Max. Continuous Discharge Current:

500A

Energy storage:

20.2kWh

Discharge Cut-off Voltage:

78Vdc

Dimensions(WxDxH):

810x550x500mm

Inquiry

Company Advantages

· battery energy storage is made-up in tune with production technology standards.

· We are committed to research and development of new technology, so that our product quality and performance is in the forefront of the industry.

· has changed its quality control system so it can deal quickly with problems on a global basis.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-96V20k-B
Energy storage	20kWh
Nominal Voltage	96Vdc
Nominal Capacity	210Ah
Maximum Charge Voltage	109.2Vdc
Discharge Cut-off Voltage	78Vdc
ESR/AC @1KHz 50% SOC	<150mΩ
Max. Continuous Charge Current	100A
Max. Continuous Discharge Current	500A
Absolute Peak Current 10s	600A
Discharge Temperature	-20℃~+60℃
Charge Temperature	0℃~+55℃
Cooling Method	Natural cooling
Operating Humidity	0~90% RH Non-condensing
Cells Self-discharge Rate	2% per month
Recommended Depth of Discharge	≤90%
Maximum Depth of Discharge	100%
Shell Material	Metal & ABS plastic
Monitoring Data	System voltage,current, temperature,SOC,SOH,cycle, cell’s voltage
Indicator light display	Capacity %
Environmental Protection	IP67
Storage Conditions	-20℃~+40℃ 25% ~ 95%RH SOC>30%，one full charge needed per two months

Weight	190kg
Dimensions(WxDxH)	810x550x500(mm)
Mount Options	On floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Features

· is born from the know-how rooted in the territory, and from the company’s strong international character. We are experienced in developing and producing battery energy storage.

· takes the leading role in technology of battery energy storage industry.

· Establishing into a world-famous brand is the ultimate goal. Check it!

Product Details

The battery energy storage we produce are able to stand up to the details.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
