Brand Capacitor Power Bank Supplier

Series:

EM Series

Part Number:

GTEM-800V57K-R

Nominal Voltage:

800Vdc

Max. Continuous Charge Current:

80A

Energy storage:

57kWh

Inquiry

Product details of the capacitor power bank

Product Overview

To enhance the competitiveness, also pays attention to the design of capacitor power bank. The quality of the product is reliable as it is in compliance with industry standards. possess strong local resource advantages.

Product Introduction

Our capacitor power bank has better quality performance by virtue of the following excellent details.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-800V57K-R
Energy storage	57kWh
Nominal Voltage	800Vdc
Maximum Charge Voltage	900Vdc
Discharge Cut-off Voltage	626Vdc
ESR/AC @1KHz 50% SOC	<100mΩ
Max. Continuous Charge Current	80A
Max. Continuous Discharge Current	150A
Operating Humidity	0~90% RH Non-condensing
Cells Self-discharge Rate	2% per month
Projected Cycle Life ( 25℃)	20,000 times
Recommended Depth of Discharge	≤ 90%
Maximum Depth of Discharge	100%
Monitoring Data	System voltage,current, temperature,SOC,SOH,cycle,cell’s voltage
Terminal	Large power energy storage terminals
Environmental Protection	Indoor
Shell Material	Metal
Parallel Connection	No limited ( add HVB )
communication	CAN, RS485

Weight	580kg
Dimensions(WxDxH)	560x700x1804(mm)
Mount Options	On floor

Company Advantages

is a enterprise that integrates production and sales of products. The main products are To improve their satisfaction for our company, we have formed a quality logistics management system to provide efficient delivery service for customers. We always insist on the production of high-quality products. Welcome customers with needs to negotiate with us!

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
