Brand Power Storage Solutions Supplier

Company Advantages

· power storage solutions has excellent cost performance.

· The quality of this offered product is in compliance with the industry standard.

· High quality service going with elaborate power storage solutions can keep more competitive.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-400V14.4K-W
Energy storage	14.4kWh
Nominal Voltage	400Vdc
Maximum Charge Voltage	453Vdc
Discharge Cut-off Voltage	292Vdc
ESR/AC @1KHz 50% SOC	<150mΩ
Max. Continuous Charge Current	50A
Max. Continuous Discharge Current	50A
Cells Self-discharge Rate	2% per month
Projected Cycle Life ( 25℃)	20,000 times
Round Trip Efficiency*1	96%
Recommended Depth of Discharge	≤90%
Maximum Depth of Discharge	100%
Cooling Method	Natural
Shell Material	Metal & ABS plastic
Communication	CANbus
Monitoring Data	System voltage,current, temperature,SOC,SOH,cycle,cell`s voltage

Weight	115kg
Dimensions(WxDxH)	700x840x194(mm)
Mount Options	Wall/ floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Features

· has become a major manufacturing base in China, supplying a majority of power storage solutions items to the world market.

· uses advanced production technology and management concepts to produce power storage solutions.

· We have upgraded our capabilities from time to time to meet the environmental and emission norms. To continue this endeavor, we are being equipped with high-end technology to deal with production waste.

Product Details

Based on the professionalism of pursuing excellence, we strive for perfection in every detail of the product.

Application of the Product

The power storage solutions produced by is widely used in industry.

has been engaged in the production of for many years and has accumulated rich industry experience. Based on that, we could provide comprehensive and excellent solutions according to actual situations and the needs of different customers.

Product Comparison

Compared with other power storage solutions, the power storage solutions produced by has the following advantages and features.
