Bulk Production Graphene Battery Ev 150A by

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-24V5000-F
Energy storage	5.0kWh
Nominal Voltage	24Vdc
Maximum Charge Voltage	29Vdc
Discharge Cut-off Voltage	20Vdc
ESR/AC @1KHz 50% SOC	<10mΩ
Max. Continuous Charge Current	150A
Max. Continuous Discharge Current	150A
Projected Cycle Life ( 25℃)	20,000 times
Recommended Depth of Discharge	≤90%
Maximum Depth of Discharge	100%
Charge Temperature	0℃~+55℃
Discharge Temperature	-20℃~+60℃
Cooling Method	Natural
Shell Material	Metal & ABS plastic
Parallel Connection	Recommend within 10sets
Monitoring Data	SOC,voltage, module

Weight	190kg
Dimensions(WxDxH)	645x565x245(mm)
Mount Options	Wall / floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Advantages

· The materials of graphene battery ev are carefully selected based on customers' specification/size requirements.

· The product is durable in use and has a relatively long service life.

· The product has been exported to many countries and gains customers' recognition.

Company Features

· mainly runs the business of producing graphene battery ev.

· We have a wide variety of talents that drives our ability to innovate. They secure us a variety of perspectives to address the challenges ahead of us. They are the source of innovative solutions and new opportunities.

· Our company is customer-focused. Everything we do begins with actively listening and collaborating with customers. By understanding their challenges and aspirations, we proactively identify solutions that address their current and future needs.

Application of the Product

graphene battery ev can be used in multiple scenes.

We are always aware of new trends and developments in the market, so we can provide our customers with the industry-leading one-stop solutions.
