Part Number |
GTEF-752V2.2MWh/1MW-C |
Nominal Voltage |
752Vdc |
Max. Charge Voltage |
846Vdc |
Standard Discharge Cut-off Voltage |
658Vdc |
Nominal Capacity |
2940Ah |
2210kWh |
|
Standard Charge Constant Current @25℃ |
1330A |
Internal Resistance |
30mΩ |
Energy Efficiency |
95%(0.5C/0.5C, @25℃) |
Heating Power |
25kW |
Cooling Method |
Forced Air |
Mode of wire entry |
Lower wiring Pattern |
IP Grade |
IP65 |
Dielectric Strength |
AC3000V@50Hz, 1min |
Communication |
CAN, RS485, LAN |
Dimensions(WxDxH) |
12192*2438*2896mm |
Mount Options |
On floor |
Company Advantages
· solar battery energy storage is carefully finished with premium materials.
· With its unique style and sophisticated technology, the performance solar battery energy storage has been magnified.
· This product is effectively applied in the industry with its compatible functions.
Company Features
· is easily distinguished from other competitors due to the excellency in developing and manufacturing quality solar battery energy storage.
· Having a team of manufacturing members is the strength of our business. They leverage various processing technologies in the production process, which can guarantee the highest level of products.
· In accordance with the requirements of high-quality development, will adhere to international standards in the solar battery energy storage production.
Application of the Product
solar battery energy storage is of excellent quality and is widely used in the industry.
can provide customers with one-stop solutions of high quality, and meet customers' needs to the greatest extent.
Welcome, Shanghai Green Tech (GTCAP) is a supercapacitor battery manufacturer and energy storage solutions provider,
offering OEM, ODM and customized energy storage solutions for customers.
