Capacitor Bank Brand 58.8Vdc 80A 1
Capacitor Bank Brand 58.8Vdc 80A 2
Capacitor Bank Brand 58.8Vdc 80A 1
Capacitor Bank Brand 58.8Vdc 80A 2

Capacitor Bank Brand 58.8Vdc 80A

Nominal Voltage:
48Vdc
Maximum Charge Voltage:
58.8Vdc
Max. Continuous Charge Current:
80A
Energy storage:
1248Wh
Discharge Cut-off Voltage:
42Vdc
Inquiry
Send your inquiry

Company Advantages

· capacitor bank is made of fully checked raw materials.

· has passed the quality management system to ensure the quality of the product.

· One of business plan is to delivering exceptional customer service.

Product Parameters
General Characteristics
Mechanical Specifications

Part Number

GTEM-48V1248-M

Energy storage

1248Wh

Nominal Voltage

48Vdc

Maximum Charge Voltage

58.8Vdc

Discharge Cut-off Voltage

42Vdc

ESR/AC @1KHz 50% SOC

<12mΩ

Max. Continuous Charge Current

80A

Max. Continuous Discharge Current

80A

Cut-off current (charging)

4A

Cells Self-discharge Rate

2% per month

Projected Cycle Life ( 25℃)

20,000 times

Recommended Depth of Discharge

≤90%

Maximum Depth of Discharge

100%

Shell Material

Metal & ABS plastic

Monitoring Data

SOC,voltage,current, temperature

Series Connection

Not allowed

Parallel Connection

Recommend within 10sets

Series-Parallel Connection

Not allowed

Weight

15.5kg

Dimensions(WxDxH)

230x180x300(mm)

Mount Options

On floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)
1 (10)
2 (9)
2 (9)
3 (7)
3 (7)
4 (7)
4 (7)
5 (8)
5 (8)
6 (11)
6 (11)
7 (6)
7 (6)

Download


Company Features

· has been spent years of efforts into developing high quality capacitor bank.

· Having a team of manufacturing members is the strength of our business. They leverage various processing technologies in the production process, which can guarantee the highest level of products.

· will serve capacitor bank with our heart and soul. Contact us!


Application of the Product

capacitor bank can be widely used in various fields.

We listen carefully to customer's requests and provide targeted solutions based on the bottleneck of customer. Therefore, we can help our customers to better solve problems.

Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
