Part Number	GTEG-23V4180-F
Energy storage	4.18kWh
Nominal Capacity	182Ah
Nominal Voltage	23Vdc
Absolute Maximum Voltage	28Vdc
Cut-off Voltage (discharging)	18Vdc
Configuration	10S13P
Pack resistance	< 10 mΩ
Continuous Charge Current	150A
Continuous Discharge Current	150A
Peak Discharge Current	300A
Recommended Depth of Discharge	90%
Maximum Depth of Discharge	100%
Cooling	Natural cooling
Ingress Protection	IP55
Storage Humidity	25% ~ 95%RH
Operating Humidity	0 – 90% RH
Storage Temperature	-20℃~40 ℃

Weight	225kg
Dimensions(WxDxH)	650195600mm
Mount Options	Wall/ floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Advantages

· household solar battery cost is manufactured with high-grade components and other materials sourced from reliable vendors.

· It is detailed tested by our professional QC team.

· The strict quality standards make worldwide export possible.

Company Features

· is a well recognized manufacturer, wholesale supplier and exporter of a splendid range of household solar battery cost.

· strongly emphasizes the importance of applying high technology.

· We have upgraded our capabilities from time to time to meet the environmental and emission norms. To continue this endeavor, we are being equipped with high-end technology to deal with production waste.

Application of the Product

The household solar battery cost produced by is widely used in field for its excellent quality.

We have a professional team and can provide customers with the most appropriate solutions to help customers achieve their goals quickly and effectively.
