Custom Capacitor Bank 486x590x133.3(mm)

Product details of the capacitor bank

Quick Detail

Our capacitor bank complies with industrial safety standards. The product meets the demanding quality standard and becomes the benchmark for quality. capacitor bank of can play a role in various industries. has created new market highlights for capacitor bank.

Product Information

More detailed information about capacitor bank is provided for you as follows.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEF-48V4500-E
Energy storage	4.71kWh
Capacity	92Ah
Nominal Voltage	51.2Vdc
Maximum Charge Voltage	57.6Vdc
Discharge Cut-off Voltage	44.8Vdc
ESR/AC @1KHz 50% SOC	<20mΩ
Max. Continuous Charge Current	50A
Max. Continuous Discharge Current	50A
Communication	CAN, RS485
Monitoring Data	System,voltage,current, temperature,SOC,SOH,cells’ voltage
Protection & Alarms	Over charge,over current,over temperature,over discharge
Anti-theft	Intelligent software lock; GPS, displacement lock,buzzer alarm
Projected Cycle Life ( 25℃)	6,000 times
Recommended Depth of Discharge	≤95%
Maximum Depth of Discharge	95%
Shell Material	Metal & ABS plastic
Cooling Method	Natural
Series Connection	Not allowed
Parallel Connection	Up to 16sets (need to clarify when place order)
Series and Parallel Connection	Add controller box (need to clarify when place order)

Weight	38kg
Dimensions(WxDxH)	486x590x133.3(mm)
Mount Options	Standard 19” rack mounted

Certificate Options

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Company Information

Currently located in is a modern company that mainly produces sticks to the business philosophy of 'high quality, high value, high efficiency'. And we adhere to the enterprise spirit of 'pragmatic, innovative, concentrated, united'. We seek development with quality and innovation and strive to achieve the aim to build a first-class brand in the industry. has a backbone team consisting of technical workers and management personnel of technique, production, quality inspection and others, which has made a strong guarantee for our continuous growth. We are committed to meeting the need of our customers. We will go deeper into their situation and provide them with most suitable solutions.
We have been providing high quality capacitor bank for a long time. We look forward to working with you.
