Custom Deep Cycle Marine Battery 100ah EM Series

Company Advantages

· Such design will certainly make deep cycle marine battery 100ah even more appealing to customers.

· The quality of this product has been highly evaluated by authoritative testing organizations based on a strict performance test and quality test.

· Sample service is available for our deep cycle marine battery 100ah.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-96V20k-B
Energy storage	20kWh
Nominal Voltage	96Vdc
Nominal Capacity	210Ah
Maximum Charge Voltage	109.2Vdc
Discharge Cut-off Voltage	78Vdc
ESR/AC @1KHz 50% SOC	<150mΩ
Max. Continuous Charge Current	100A
Max. Continuous Discharge Current	500A
Absolute Peak Current 10s	600A
Discharge Temperature	-20℃~+60℃
Charge Temperature	0℃~+55℃
Cooling Method	Natural cooling
Operating Humidity	0~90% RH Non-condensing
Cells Self-discharge Rate	2% per month
Recommended Depth of Discharge	≤90%
Maximum Depth of Discharge	100%
Shell Material	Metal & ABS plastic
Monitoring Data	System voltage,current, temperature,SOC,SOH,cycle, cell’s voltage
Indicator light display	Capacity %
Environmental Protection	IP67
Storage Conditions	-20℃~+40℃ 25% ~ 95%RH SOC>30%，one full charge needed per two months

Weight	190kg
Dimensions(WxDxH)	810x550x500(mm)
Mount Options	On floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Features

· has a sound management system to ensure the quality of deep cycle marine battery 100ah.

· Covering a large area, our factory features reasonable production conditions. Its layout is in line with international regulations and standards, including illumination condition and standard production facilities. We have increased our market share of our products including deep cycle marine battery 100ah through multiple channels. And we have also established a solid customer base around the world.

· Our staff always adhere to the principle of customer first. Please contact us!

Product Details

The details of deep cycle marine battery 100ah are presented to you in the following section.

Product Comparison

39;s technical level is higher than its peers. Compared with peer products, the deep cycle marine battery 100ah produced by us has the following highlights.
