Custom Deep Cycle Marine Battery 120A 512Vd.c

Product details of the deep cycle marine battery

Product Overview

deep cycle marine battery is widely known for its attractive design. The quality of the product can stand the test of time. The deep cycle marine battery produced by our company is widely recognized by customers and widely used in field. This product has achieved good results in practical applications.

Product Information

pursues excellent quality and strives for perfection in every detail during the production.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEF-512V50KW/100KWH-R
Energy storage	107.5kWh
Nominal Voltage	512Vd.c
Maximum Charge Voltage	576Vd.c
Discharge Cut-off Voltage	448Vd.c
ESR/AC @1KHz 50% SOC	<100mΩ
Max. Continuous Charge Current	120A
Max. Continuous Discharge Current	120A
Operating Humidity	0~90% RH Non-condensing
Cells Self-discharge Rate	2% per month
Projected Cycle Life ( 25℃)	10,000 times
Recommended Depth of Discharge	≤ 90%
Maximum Depth of Discharge	100%
Monitoring Data	System voltage,current, temperature,SOC,SOH,cycle,cell’s voltage
Terminal	Large power energy storage terminals
Environmental Protection	IP20 Indoor
Shell Material	Metal
Parallel Connection	No limited ( add controller box )
communication	CAN, RS485, TCP

Weight	1315kg
Dimensions(WxDxH)	801x832x1629(mm)
Mount Options	On floor

Certificate Options

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Company Information

located in is a comprehensive enterprise. We are dedicated to the production and sales of sets up service outlets in key areas, so as to make a rapid response to customers' requirement. The products produced are qualified products of high quality. If you are interested in our products, please contact us!
