Product details of the graphene batteries for electric cars

Product Information

From raw material procurement to the development phase, each link of the graphene batteries for electric cars is strictly controlled. This product has comprehensive functionality and stable performance thanks to the quality inspections conducted by our dedicated team. has the most advanced technology and innovative capabilities for graphene batteries for electric cars.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTSM-48V165FUS
Nominal capacitance	125 F
Capacitance tolerance	-10%~~+20%
Rated voltage	48V
Maximum absolute voltage	51V
ESR, DC	5 mΩ
Maximum continuous current (ΔT=40℃)	100 A
Maximum peak current, 1 sec.	2,275 A
Maximum leakage current (after 72hrs @ 25℃)	5.2 mA
Operating temperature range (Cell case temperature)	-40℃ to +65℃
Storage temperature range(Storage uncharged)	-40℃ to +70℃
Power terminals	M8 Screw Hole
Negative Terminal	M10 Screw Hole
Recommended torque - terminal	20/30 Nm
Vibration specification	SAE J2380 ISO16750-2, T14
Shock specification	SAE J2464
Colling	Natural Convection

Weight	20kg
Environmental protection	IP65
Internal temperature sensor	NTC Thermistor
Cell voltage monitoring	Overvoltage Alarm

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Feature

• Our company was founded in and our business scope has been expanding continuously. However, our product quality will always stay the same. And we are ready to provide more quality products for consumers wholeheartedly.
• We always put our customers first and treat each customer sincerely. Besides, we strive to meet the requirements of customers, and solve their problems duly.
• Good location advantages and developed transportation and infrastructure are conducive to long-term development.
• are sold well in all parts of the country. They are of good quality and affordable price, which are deeply favored by the majority of customers.
insists on producing in various materials and sizes. We are available in sufficient stock and customers could purchase freely according to the needs. Please feel free to contact us to order.
