Custom Graphene Battery for Ev 150A

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-800V57K-R
Energy storage	57kWh
Nominal Voltage	800Vdc
Maximum Charge Voltage	900Vdc
Discharge Cut-off Voltage	626Vdc
ESR/AC @1KHz 50% SOC	<100mΩ
Max. Continuous Charge Current	80A
Max. Continuous Discharge Current	150A
Operating Humidity	0~90% RH Non-condensing
Cells Self-discharge Rate	2% per month
Projected Cycle Life ( 25℃)	20,000 times
Recommended Depth of Discharge	≤ 90%
Maximum Depth of Discharge	100%
Monitoring Data	System voltage,current, temperature,SOC,SOH,cycle,cell’s voltage
Terminal	Large power energy storage terminals
Environmental Protection	Indoor
Shell Material	Metal
Parallel Connection	No limited ( add controller box )
communication	CAN, RS485, LAN

Weight	580kg
Dimensions(WxDxH)	560x700x1804(mm)
Mount Options	On floor

Certificate Options

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Company Advantages

· All the processes of graphene battery for ev are conducted smoothly with advanced facility manned with highly qualified professionals.

· Through the devotion to the performance of graphene battery for ev, has received more and more orders.

· will strive to maintain sustained profit growth and capacity enhancement in the already competitive areas.

Company Features

· As a well-known company, is specialized in manufacturing graphene battery for ev.

· graphene battery for ev is made by our best technology.

· Every worker is making a powerful competitor on the market. Ask online!

Application of the Product

The graphene battery for ev produced by is widely used in the industry.

In addition to high-quality products, also provides effective solutions based on the actual conditions and the needs of different customers.
