Custom Panel Capacitor Bank 486x590x133.3(mm)

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEF-48V4500-E
Energy storage	4.71kWh
Capacity	92Ah
Nominal Voltage	51.2Vdc
Maximum Charge Voltage	57.6Vdc
Discharge Cut-off Voltage	44.8Vdc
ESR/AC @1KHz 50% SOC	<20mΩ
Max. Continuous Charge Current	50A
Max. Continuous Discharge Current	50A
Communication	CAN, RS485
Monitoring Data	System,voltage,current, temperature,SOC,SOH,cells’ voltage
Protection & Alarms	Over charge,over current,over temperature,over discharge
Anti-theft	Intelligent software lock; GPS, displacement lock,buzzer alarm
Projected Cycle Life ( 25℃)	6,000 times
Recommended Depth of Discharge	≤95%
Maximum Depth of Discharge	95%
Shell Material	Metal & ABS plastic
Cooling Method	Natural
Series Connection	Not allowed
Parallel Connection	Up to 16sets (need to clarify when place order)
Series and Parallel Connection	Add controller box (need to clarify when place order)

Weight	38kg
Dimensions(WxDxH)	486x590x133.3(mm)
Mount Options	Standard 19” rack mounted

Certificate Options

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Company Advantages

· panel capacitor bank is produced under highly standardized production environment.

· International advanced technology is imported to improve its performance. .

· Only high quality panel capacitor bank will be sent out to customers.

Company Features

· is among the fastest-growing production firm in China. We supply high-quality products, for example, panel capacitor bank.

· Our company has a trained and well-educated workforce. Keeping up to date on the trends in the panel capacitor bank industry, they can always offer the best recommendations and insights to clients and prospects.

· We consciously to conduct good business actions. We have made corresponding plans to achieve sustainability. We will try to readjust our industrial structure to a clean and environmental-friendly level.

Application of the Product

panel capacitor bank of can be used in different industries to meet the needs of customers in different fields.

always pays attention to customers. According customers' actual needs, we could customize comprehensive and professional solutions for them.
