Nominal Capacity:
210Ah
Maximum Charge Voltage:
806.4Vdc
Energy storage:
150.5kWh
Discharge Cut-off Voltage:
604.8Vdc
Dimensions(WxDxH):
801x832x2166(mm)
Inquiry
Send your inquiry

Product details of the panel capacitor bank


Product Introduction

It is necessary for to change with the fashions to design panel capacitor bank. Strict quality standards have been set in the inspection process, ensuring the high quality of the product. has achieved a good reputation in the world's panel capacitor bank industry.

Product Parameters
General Characteristics
Mechanical Specifications

Part Number

GTEF-716V100K-R

Energy storage

150.5kWh

Nominal Voltage

716.8Vdc

Maximum Charge Voltage

806.4Vd.c (Recommended high voltage limit:784V)

Discharge Cut-off Voltage

604.8Vd.c (Recommended low voltage limit: 627.2V)

ESR/AC @1KHz 50% SOC

<150mΩ

Max. Continuous Charge Current

150A

Max. Continuous Discharge Current

150A

Operating Humidity

0~90% RH Non-condensing

Cells Self-discharge Rate

2% per month

Projected Cycle Life ( 25℃)

10,000 times(70%EOL)

Recommended Depth of Discharge

≤ 90%

Maximum Depth of Discharge

100%

Monitoring Data

System voltage,current, temperature,SOC,SOH,cycle,cell’s voltage

Terminal

Large power energy storage terminals

Environmental Protection

IP20 Indoor

Shell Material

Metal

Parallel Connection

 No limited ( add controller box )

communication

CAN, RS485, LAN

Weight

1560kg

Dimensions(WxDxH)

801x832x2166(mm)

Mount Options

On floor
