Customized High Voltage Capacitor Bank Series for Business

Company Advantages

· The raw materials of high voltage capacitor bank are highly secured by selecting reliable suppliers.

· The product has passed the accreditation of ISO9001 quality management system.

· The product has high customer satisfaction and shows a wider market potential.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTSM-48V165FUS
Nominal capacitance	125 F
Capacitance tolerance	-10%~~+20%
Rated voltage	48V
Maximum absolute voltage	51V
ESR, DC	5 mΩ
Maximum continuous current (ΔT=40℃)	100 A
Maximum peak current, 1 sec.	2,275 A
Maximum leakage current (after 72hrs @ 25℃)	5.2 mA
Operating temperature range (Cell case temperature)	-40℃ to +65℃
Storage temperature range(Storage uncharged)	-40℃ to +70℃
Power terminals	M8 Screw Hole
Negative Terminal	M10 Screw Hole
Recommended torque - terminal	20/30 Nm
Vibration specification	SAE J2380 ISO16750-2, T14
Shock specification	SAE J2464
Colling	Natural Convection

Weight	20kg
Environmental protection	IP65
Internal temperature sensor	NTC Thermistor
Cell voltage monitoring	Overvoltage Alarm

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Features

· is China's major high voltage capacitor bank production base.

· We have an experienced project management team that acts as the role of our business success. Their manufacturing management expertise ensures quick turnaround times and excellent quality for our high voltage capacitor bank.

· We have a simple business philosophy. We always work closely with clients to provide a comprehensive balance of performance and pricing effectiveness.

Application of the Product

high voltage capacitor bank can be used in multiple industries.

We have a professional team and can provide customers with the most appropriate solutions to help customers achieve their goals quickly and effectively.

Product Comparison

The high voltage capacitor bank produced by is better than the previous generation. The specific performance is as follows.
