Deep Cycle Marine Battery 100ah EG Series

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEG-700V39K-R
Energy storage	39.4kWh
Nominal Voltage	703.8Vdc
Maximum Charge Voltage	856.8Vdc
Discharge Cut-off Voltage	642.6Vdc
ESR/AC @1KHz 50% SOC	<100mΩ
Max. Continuous Charge Current	280A
Max. Continuous Discharge Current	280A
Discharge rate	5C
Max. Continuous Output Power	196kW
Charge Temperature*1	-20℃~+60℃
Discharge Temperature*2	-40℃~+60℃
Operating Humidity	0~90% RH Non-condensing
Cells Self-discharge Rate	2% per month
Projected Cycle Life ( 25℃)	50,000 times
Recommended Depth of Discharge	≤ 90%
Maximum Depth of Discharge	100%
Monitoring Data	System voltage,current, temperature,SOC,SOH,cycle,cell’s voltage
Terminal	Large power energy storage terminals
Environmental Protection	Indoor
Cooling Method	Liquid cooling ( cycle frequently )
Shell Material	Metal
Parallel Connection	No limited ( add controller box )
communication	CAN, RS485

Weight	580kg
Dimensions(WxDxH)	560x700x1804(mm)
Mount Options	On floor

Certificate

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Company Advantages

· All products from deep cycle marine battery 100ah are independently designed and manufactured by

· As we always keep 'Quality first' firmly in mind, the product is sure to be of the highest quality.

· sticks to maximize customer interests, to meet customers' special needs of a variety of deep cycle marine battery 100ah.

Company Features

· is a standard deep cycle marine battery 100ah manufacturer.

· Our factory has advanced manufacturing machines. The use of these machines means that all major operations are automated or semi-automated and that increases the speed and quality of products.

· will continue to create profits for customers. Inquiry!

Application of the Product

deep cycle marine battery 100ah can be used in many industries.

With professional engineers and technicians in our company, is able to provide one-stop and comprehensive solutions for customers.
