Eco Friendly Group 27 Deep Cycle Battery for House

Part Number:
GTSM-16V-500FUS
Max. Continuous Discharge Current:
100A
Max. Continuous Charge Current:
100A
Energy storage:
500F
Dimensions(WxDxH):
417x67x178mm
Inquiry

Product details of the group 27 deep cycle battery


Quick Detail

There is a fact that the function of group 27 deep cycle battery is well-designed to match the needs of the products. In order to ensure the quality of the product, our expert team will careful and strictly check the quality in every stage of production. Our group 27 deep cycle battery can be used in multiple scenarios. has a wide range of influence in the country.


Product Description

pursues excellent quality and strives for perfection in every detail during the production.

Product Parameters
General Characteristics
Mechanical Specifications

Part Number

GTSM-16V-500FUS

Nominal capacitance

500 F

Capacitance tolerance

+20% / -0%

Rated voltage

16V

Maximum absolute voltage

17V

Maximum series voltage

750V

ESR, DC

1.8mΩ

Maximum continuous current (ΔT=40℃)

100 A

Maximum peak current, 1 sec.

2,275 A

Maximum leakage current (after 72hrs @ 25℃)

5.2 mA

Operating temperature range(Cell case temperature)

-40℃ to +65℃

Storage temperature range(Storage uncharged)

-40℃ to +70℃

Power terminals

M8/M10

Recommended torque - terminal

20/30 Nm

Vibration specification

GB-T 11287-2000

Shock specification

GBT 14537-1993

Environmental protection

IP65

Weight

5.7 kg

Internal temperature sensor

NTC Thermistor

Cell voltage monitoring

Overvoltage Alarm

Usable power density (Pd)

3,590 W/kg

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)
1 (10)
2 (9)
2 (9)
3 (7)
3 (7)
4 (7)
4 (7)
5 (8)
5 (8)
6 (11)
6 (11)
7 (6)
7 (6)

Download


Company Information

is an economic power in group 27 deep cycle battery field with its own powerful manufacturing capability. is especially prominent in terms of technological and scientific capacities. To ensure that we all act with the utmost standards, we have created an environmental policy for everyone to adhere to. The environmental policy is under the direct control of the managing director of the company. Get quote!
We look forward to working with you to move towards a more brilliant era.

Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
