The production of best deep cycle marine battery is supervised by experienced and skilled staff. The product is highly preferred by our clients for its competitive advantages of high quality, stable performance, strong practicality. has established a sound quality control system to make sure the quality of the product.

Product Description

Compared with general products, the best deep cycle marine battery we produce have the following advantages.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-24V3200-E
Energy storage	3.2kWh
Nominal Voltage	24Vdc
Maximum Charge Voltage	29Vdc
Discharge Cut-off Voltage	20Vdc
ESR/AC @1KHz 50% SOC	<15Ω
Max. Continuous Charge Current	40A
Max. Continuous Discharge Current	40A
Cells Self-discharge Rate	2% per month
Projected Cycle Life ( 25℃)	20,000 times
*Round Trip Efficiency1**	96%
Recommended Depth of Discharge	≤90%
Maximum Depth of Discharge	100%
Cooling Method	Natural
Shell Material	Metal & ABS plastic
Monitoring Data	System voltage,current, temperature,SOC,SOH,cycle,cell`s voltage

Weight	20kg
Dimensions(WxDxH)	347x224x200mm
Mount Options	Wall/ floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet
