Factory Direct Battery Energy Storage System - SM Series

Product details of the battery energy storage system

Quick Detail

The design of battery energy storage system follows the latest trends. Stable performance and long lifespan of battery energy storage system is guaranteed. In order to meet the requirements of clients, has been satisfying them with high quality battery energy storage system.

Product Description

The battery energy storage system of has the following advantages compared with battery energy storage system in the market.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTSM-48V165FUS
Nominal capacitance	125 F
Capacitance tolerance	-10%~~+20%
Rated voltage	48V
Maximum absolute voltage	51V
ESR, DC	5 mΩ
Maximum continuous current (ΔT=40℃)	100 A
Maximum peak current, 1 sec.	2,275 A
Maximum leakage current (after 72hrs @ 25℃)	5.2 mA
Operating temperature range (Cell case temperature)	-40℃ to +65℃
Storage temperature range(Storage uncharged)	-40℃ to +70℃
Power terminals	M8 Screw Hole
Negative Terminal	M10 Screw Hole
Recommended torque - terminal	20/30 Nm
Vibration specification	SAE J2380 ISO16750-2, T14
Shock specification	SAE J2464
Colling	Natural Convection

Weight	20kg
Environmental protection	IP65
Internal temperature sensor	NTC Thermistor
Cell voltage monitoring	Overvoltage Alarm

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet
