Factory Direct Solar Battery Energy Storage - SM Series

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTSM-48V165FUS
Nominal capacitance	125 F
Capacitance tolerance	-10%~~+20%
Rated voltage	48V
Maximum absolute voltage	51V
ESR, DC	5 mΩ
Maximum continuous current (ΔT=40℃)	100 A
Maximum peak current, 1 sec.	2,275 A
Maximum leakage current (after 72hrs @ 25℃)	5.2 mA
Operating temperature range (Cell case temperature)	-40℃ to +65℃
Storage temperature range(Storage uncharged)	-40℃ to +70℃
Power terminals	M8 Screw Hole
Negative Terminal	M10 Screw Hole
Recommended torque - terminal	20/30 Nm
Vibration specification	SAE J2380 ISO16750-2, T14
Shock specification	SAE J2464
Colling	Natural Convection

Weight	20kg
Environmental protection	IP65
Internal temperature sensor	NTC Thermistor
Cell voltage monitoring	Overvoltage Alarm

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Advantages

· All production processes of solar battery energy storage are operated at the highest possible standards.

· A strict quality guarantee system has been established to ensure that the product is qualified in all respects, such as performance and durability.

· has more interaction with customers.

Company Features

· is an important enterprise specialized in solar battery energy storage in China.

· has achieved intensive growth based on technological innovation and industrial upgrading.

· aims to be an influential and a competent company in the future. Check it!

Application of the Product

Multiple in function and wide in application, solar battery energy storage can be used in many industries and fields.

In addition to providing high-quality products, we also provide effective solutions based on the actual conditions and the needs of different customers.
