Part Number |
GTEM-48V10k-B |
10kWh |
|
Nominal Voltage |
51.8Vdc |
Nominal Capacity |
210Ah |
Maximum Charge Voltage |
58Vdc |
Discharge Cut-off Voltage |
40Vdc |
ESR/AC @1KHz 50% SOC |
<15mΩ |
Max. Continuous Charge Current |
200A |
Max. Continuous Discharge Current |
200A |
Absolute Peak Current 3s |
300A |
Discharge Temperature |
-20℃~+60℃ |
Charge Temperature |
0℃~+55℃ |
Cooling Method |
Natural cooling |
Operating Humidity |
0~90% RH Non-condensing |
Cells Self-discharge Rate |
2% per month |
Recommended Depth of Discharge |
≤90% |
Maximum Depth of Discharge |
100% |
Shell Material |
Stainless steel
|
Monitoring Data |
System voltage,current, temperature,SOC,SOH,cycle, cell’s voltage |
Indicator light display |
Capacity % |
Environmental Protection |
IP65 |
Storage Conditions |
-20℃~+40℃ 25% ~ 95%RH SOC>30%,one full charge needed per two months |
Weight |
82kg |
Dimensions(WxDxH) |
1124x400x256(mm) |
Mount Options |
On floor |
Compatible Protocol: CAN, RS485
Company Advantages
· supercapacitor bank is inspected right from raw materials selection to the final production.
· This product has passed related qualifications and international certifications.
· This product is widely appreciated among our customers for its wide range of applications.
Company Features
· Over the years, has been putting efforts on providing high-quality and innovative supercapacitor bank, which sets us apart from the competition.
· We not only have our product throughout the country but also exported to Europe, America, Southeast Asia, and so forth. We have also finished several projects with some world-famous brands.
· Our mission is clear. We keep up with the rapid changes in the modern age, maintaining the core values and strive to provide the best service to our customers.
Application of the Product
supercapacitor bank developed and produced by our company can be widely used in various industries and professional fields.
We are willing to understand the real needs of our customers. Then, we will provide the best solutions to their needs.
