For Sea Water Graphene Battery Ev 150A by

Company Advantages

· graphene battery ev has advantages of good quality material and special design.

· The product has been recognized with ISO 9001 certification.

· Centering on the process management from design to production turns out to be effective to ensure the quality of graphene battery ev.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEF-716V100K-R
Energy storage	150.5kWh
Nominal Voltage	716.8Vdc
Maximum Charge Voltage	806.4Vd.c (Recommended high voltage limit:784V)
Discharge Cut-off Voltage	604.8Vd.c (Recommended low voltage limit: 627.2V)
ESR/AC @1KHz 50% SOC	<150mΩ
Max. Continuous Charge Current	150A
Max. Continuous Discharge Current	150A
Operating Humidity	0~90% RH Non-condensing
Cells Self-discharge Rate	2% per month
Projected Cycle Life ( 25℃)	10,000 times(70%EOL)
Recommended Depth of Discharge	≤ 90%
Maximum Depth of Discharge	100%
Monitoring Data	System voltage,current, temperature,SOC,SOH,cycle,cell’s voltage
Terminal	Large power energy storage terminals
Environmental Protection	IP20 Indoor
Shell Material	Metal
Parallel Connection	No limited ( add controller box )
communication	CAN, RS485, LAN

Weight	1560kg
Dimensions(WxDxH)	801x832x2166(mm)
Mount Options	On floor

Certificate Options

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Company Features

· excels well in the manufacturing of graphene battery ev. We have been known as a professional manufacturer in China.

· Our factory delivers standardized production which is yielded by well-trained and highly motivated employees in combination with the most modern and eco-friendly machinery.

· graphene battery ev will serve you with our heart and soul. Welcome to visit our factory!

Product Details

graphene battery ev produced by are of excellent quality and the specific details are as follows.

Application of the Product

The graphene battery ev produced by is very popular in the market and is widely used in industry.

With rich manufacturing experience and strong production capability, is able to provide professional solutions according to customers' actual needs.

Product Comparison

The graphene battery ev of has the following advantages, compared with similar products in the market.

Enterprise Advantages

We have the powerful team management, strong production team, customer-focused business team, and inexorable research and development team to offer favorable conditions for our development.

On the basis of reputation, we seek the organic combination of culture, technology and talents to gain benefit. We provide our customers with quality, thoughtful and fast service.

Pursuing for excellence and always making progress is our business concept. And we operate our business based on the integrity and dedication. All this will create an excellent brand image in industry.

After years of production experience, our company has repeatedly updated our technology and improved product quality. We will continue to work hard to become a leader in the industry.

Based on the domestic market, our company is also actively exploring foreign markets.
