Series:
EM Series
Nominal Voltage:
51.8Vdc
Maximum Charge Voltage:
58Vdc
Max. Continuous Discharge Current:
200A
Max. Continuous Charge Current:
200A
Inquiry

Product details of the energy storage solution


Product Information

energy storage solution is exquisite in craftsmanship. energy storage solution is a product which has many qualities and has a large assortment of applications it is suitable for. Compared with other energy storage solution manufacturers, GREEN TECH has more comprehensive R&D capabilities.

Product Parameters
General Characteristics
Mechanical Specifications

Part Number

GTEM-48V10k-B

Energy storage

10kWh

Nominal Voltage

51.8Vdc

Nominal Capacity

210Ah

Maximum Charge Voltage

58Vdc

Discharge Cut-off Voltage

40Vdc

ESR/AC @1KHz 50% SOC

<15mΩ

Max. Continuous Charge Current

200A

Max. Continuous Discharge Current

200A

Absolute Peak Current 3s

300A

Discharge Temperature

-20℃~+60℃

Charge Temperature

0℃~+55℃

Cooling Method

Natural cooling

Operating Humidity

0~90% RH Non-condensing

Cells Self-discharge Rate

2% per month

Recommended Depth of Discharge

≤90%

Maximum Depth of Discharge

100%

Shell Material

Stainless steel

Monitoring Data

System voltage,current, temperature,SOC,SOH,cycle,

cell’s voltage

Indicator light display

Capacity %

Environmental Protection

IP65

Storage Conditions

-20℃~+40℃

25% ~ 95%RH

SOC>30%,one full charge needed per two months

Weight

82kg

Dimensions(WxDxH)

1124x400x256(mm)

Mount Options

On floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485
