The advanced technology is integrated into the whole production process of graphene batteries in cars. Every stage of the production process is strictly monitored to ensure the quality of this product. Our customers can send email or call us directly if any problem for our graphene batteries in cars.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-800V96KW-57KWH-R
Energy storage	57.5kWh
Nominal Voltage	799.2Vd.c
Maximum Charge Voltage	896.4Vd.c
Discharge Cut-off Voltage	648Vd.c
ESR/AC @1KHz 50% SOC	<70mΩ
Max. Continuous Charge Current	80A
Max. Continuous Discharge Current	120A
Cooling Method	Natural
Recommended Depth of Discharge	≤90%
Maximum Depth of Discharge	100%
Shell Material	Metal
Monitoring Data	System voltage,current, temperature,SOC,SOH,cell’s voltage
Parallel Connection	Up to 16 parallel connections allowed
Storage Conditions	-20℃~+40℃ 25%~95%RH SOC>30%, one full charge needed per two months

Weight	550kg
Dimensions(WxDxH)	600x870x1450（mm）

Certificate&Compatible Protocol

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)
