Graphene Battery Electric Car Factory Direct Supply Bulk Production 417x190x176mm 1
Graphene Battery Electric Car Factory Direct Supply Bulk Production 417x190x176mm 2
Graphene Battery Electric Car Factory Direct Supply Bulk Production 417x190x176mm 1
Graphene Battery Electric Car Factory Direct Supply Bulk Production 417x190x176mm 2

Graphene Battery Electric Car Factory Direct Supply Bulk Production 417x190x176mm

Weight:
20kg
Series:
SM Series
Max. Continuous Charge Current:
100 A
Energy storage:
125 F
Dimensions(WxDxH):
417x190x176mm
Inquiry
Send your inquiry

Product details of the graphene battery electric car


Quick Overview

graphene battery electric car is manufactured under the guidance of experienced professionals using the best materials and modern technology. After thousands of testings, the product is ensured to have a first-class quality. Each our graphene battery electric car is produced with finest quality.


Product Introduction

graphene battery electric car's outstanding advantages are as follows.

Product Parameters
General Characteristics
Mechanical Specifications

Part Number

GTSM-48V165FUS

Nominal capacitance

125 F

Capacitance tolerance

-10%~~+20%

Rated voltage

48V

Maximum absolute voltage

51V

ESR, DC

5 mΩ

Maximum continuous current (ΔT=40℃)

100 A

Maximum peak current, 1 sec.

2,275 A

Maximum leakage current (after 72hrs @ 25℃)

5.2 mA

Operating temperature range (Cell case temperature)

-40℃ to +65℃

Storage temperature range(Storage uncharged)

-40℃ to +70℃

Power terminals

M8 Screw Hole

Negative Terminal

M10 Screw Hole

Recommended torque - terminal

20/30 Nm

Vibration specification

SAE J2380

ISO16750-2, T14

Shock specification

SAE J2464

Colling

Natural Convection

Weight

20kg

Environmental protection

IP65

Internal temperature sensor

NTC Thermistor

Cell voltage monitoring

Overvoltage Alarm

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)
1 (10)
2 (9)
2 (9)
3 (7)
3 (7)
4 (7)
4 (7)
5 (8)
5 (8)
6 (11)
6 (11)
7 (6)
7 (6)

Download


Company Advantages

has developed rapidly and is a leader in the world graphene battery electric car market. now has been developed into a famous brand named that is specialized in producing graphene battery electric car. will always bring customers with reliable products. Get quote!
We sincerely welcome people from all walks of life to come to make cooperation, common development and a better future.

Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
