The superior raw materials of graphene battery price are sourced from top-grade suppliers. introduces an efficient quality management system to effectively guarantee its quality. stays ahead of demand and achieve peak efficiency with excellent customer service.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-48V15K-W
Energy storage	15.2kWh
Nominal Voltage	48Vdc
Maximum Charge Voltage	58.8Vdc
Discharge Cut-off Voltage	39.2Vdc
ESR/AC @1KHz 50% SOC	<6mΩ
Max. Continuous Charge Current	200A
Max. Continuous Discharge Current	200A
Power/Energy	0.347
Cells Self-discharge Rate	2% per month
Projected Cycle Life ( 25℃)	10,000 times
*Round Trip Efficiency1**	98%
Recommended Depth of Discharge	≤90%
Maximum Depth of Discharge	100%
Cooling Method	Natural
Shell Material	Metal & ABS plastic
Parallel Connection	Up to 5 sets
Monitoring Data	System voltage,current, temperature,SOC,SOH,cycle,cell`s voltage

Weight	90kg
Dimensions(WxDxH)	700x845x194(mm)
Mount Options	Wall/ floor

Certificate Options

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Company Advantage

• sales network covers major provinces, cities and autonomous regions in the country. In addition, are favored by overseas customers and are sold to Southeast Asia, Africa, Australia, and other countries and regions.
• Our company is close to the road with convenient transportation. It facilitates the transportation of products and guarantees the timely supply of products.
• Since the establishment in our company has been devoted to continuous development for years. Now, we become a member of the industry leaders.
• Our company wholeheartedly provides quality services for customers at home and abroad, so as to achieve mutual benefit and win-win results.
Hello, welcome to official website! If you have any needs, please call us. We will sincerely provide you with the most professional service.
