Gridscale Energy Storage for Sale - 2 1
Gridscale Energy Storage for Sale - 2 2
Gridscale Energy Storage for Sale - 2 1
Gridscale Energy Storage for Sale - 2 2

Gridscale Energy Storage for Sale - 2

Weight:
20kg
Nominal Voltage:
48V
Maximum Charge Voltage:
51V
Max. Continuous Discharge Current:
2,275 A
Energy storage:
125 F
Inquiry

Product details of the gridscale energy storage


Product Information

The individualized design of gridscale energy storage has attracted many customers so far. This product is under the stringent observation of our quality controllers. The product finds its wide application in the industry.

Product Parameters
General Characteristics
Mechanical Specifications

Part Number

GTSM-48V165FUS

Nominal capacitance

125 F

Capacitance tolerance

-10%~~+20%

Rated voltage

48V

Maximum absolute voltage

51V

ESR, DC

5 mΩ

Maximum continuous current (ΔT=40℃)

100 A

Maximum peak current, 1 sec.

2,275 A

Maximum leakage current (after 72hrs @ 25℃)

5.2 mA

Operating temperature range (Cell case temperature)

-40℃ to +65℃

Storage temperature range(Storage uncharged)

-40℃ to +70℃

Power terminals

M8 Screw Hole

Negative Terminal

M10 Screw Hole

Recommended torque - terminal

20/30 Nm

Vibration specification

SAE J2380

ISO16750-2, T14

Shock specification

SAE J2464

Colling

Natural Convection

Weight

20kg

Environmental protection

IP65

Internal temperature sensor

NTC Thermistor

Cell voltage monitoring

Overvoltage Alarm

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485
