Group 27 Deep Cycle Battery Manufacture GTEG-23V4180-F

Product details of the group 27 deep cycle battery

Quick Detail

The material of group 27 deep cycle battery is safe even for children. Its quality will be fully tested by our experienced staff before it gets loaded. The production process of group 27 deep cycle battery complies with international standards.

Product Information

With a focus on quality, pays great attention to the details of group 27 deep cycle battery.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEG-23V4180-F
Energy storage	4.18kWh
Nominal Capacity	182Ah
Nominal Voltage	23Vdc
Absolute Maximum Voltage	28Vdc
Cut-off Voltage (discharging)	18Vdc
Configuration	10S13P
Pack resistance	< 10 mΩ
Continuous Charge Current	150A
Continuous Discharge Current	150A
Peak Discharge Current	300A
Recommended Depth of Discharge	90%
Maximum Depth of Discharge	100%
Cooling	Natural cooling
Ingress Protection	IP55
Storage Humidity	25% ~ 95%RH
Operating Humidity	0 – 90% RH
Storage Temperature	-20℃~40 ℃

Weight	225kg
Dimensions(WxDxH)	650*195*600mm
Mount Options	Wall/ floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Introduction

situated in is mainly dedicated to the business of Based on people-oriented business, pays great attention to integrity during development. Our core value is to pursue excellence and achieve mutual benefit. We constantly improve production technology, so as to provide consumers with better products and more professional services. It is our commitment to become a well-known modern enterprise in China. brings together a group of top-notch technical and management talents, who lay a solid foundation for the R&D and production with solid professional skills and knowledge. has a team of experienced professionals, mature technology and a sound service system. All this can provide customers with one-stop solutions.
The products we produced are excellent in quality and cost-effective. If in need, please contact us!
