High Voltage Capacitor Bank 20Vdc Company

Product details of the high voltage capacitor bank

Quick Overview

Professional design for high voltage capacitor bank is a big advantage for Its quality is guaranteed as its quality testing tends to be more rigorous and controlled based on the international standards instead of the national rules. The high voltage capacitor bank produced by is widely used in industry. The product is gaining larger market clout and wider application.

Product Information

Compared with products in the same category, high voltage capacitor bank we produce is equipped with the following advantages.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-24V5000-F
Energy storage	5.0kWh
Nominal Voltage	24Vdc
Maximum Charge Voltage	29Vdc
Discharge Cut-off Voltage	20Vdc
ESR/AC @1KHz 50% SOC	<10mΩ
Max. Continuous Charge Current	150A
Max. Continuous Discharge Current	150A
Projected Cycle Life ( 25℃)	20,000 times
Recommended Depth of Discharge	≤90%
Maximum Depth of Discharge	100%
Charge Temperature	0℃~+55℃
Discharge Temperature	-20℃~+60℃
Cooling Method	Natural
Shell Material	Metal & ABS plastic
Parallel Connection	Recommend within 10sets
Monitoring Data	SOC,voltage, module

Weight	190kg
Dimensions(WxDxH)	645x565x245(mm)
Mount Options	Wall / floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Information

located in is a modern company. We are specializing in the production and sales of runs a comprehensive product supply and after-sales service system. We are committed to providing thoughtful services for customers, so as to develop their greater sense of trust for the company. We are looking forward to developing a better future with you.
