High Voltage Capacitor Bank 720x355x252mmpersonalized

Company Advantages

· The production of high voltage capacitor bank follows the international standards and green norms.

· The excellent design of high voltage capacitor bank will bring you great convenience.

· In All high voltage capacitor bank can all be customized to the unique needs of individual clients.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-48V4500-G
Energy storage	4.5kWh
Nominal Voltage	48Vdc
Nominal Capacity	130Ah
Maximum Charge Voltage	58.8Vdc
Discharge Cut-off Voltage	40Vdc
ESR/AC @1KHz 50% SOC	<30mΩ
Max. Continuous Charge Current	200A
Max. Continuous Discharge Current	200A
Absolute Peak Current 3s	400A
Discharge Temperature	-20℃~+60℃
Charge Temperature	0℃~+55℃
Cooling Method	Natural cooling
Operating Humidity	0~90% RH Non-condensing
Cells Self-discharge Rate	2% per month
Projected Cycle Life ( 25℃)	20,000 times
Recommended Depth of Discharge	≤90%
Maximum Depth of Discharge	100%
Shell Material	Metal & ABS plastic
Monitoring Data	Module voltage,SOC
Indicator light display	Capacity %
Environmental Protection	IP65
Storage Conditions	-20℃~+40℃ 25% ~ 95%RH SOC>30%，one full charge needed per two months

Weight	55kg
Dimensions(WxDxH)	720x355x252(mm)
Mount Options	On floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Features

· As one of the most popular high voltage capacitor bank manufacturer, enjoys higher reputation in the market.

· has a workforce of highly skilled and reliable staff and talents for high voltage capacitor bank. The technological equipment of and its technical level for high voltage capacitor bank comes up to the advanced level in China. is equipped with a batch of the state-of-art production machine for high voltage capacitor bank.

· is well prepared to provide best high voltage capacitor bank and service to every customer. Inquiry!

Product Details

In the production process of high voltage capacitor bank, we carefully polish the details, so as to strive for perfect quality.
