High Voltage Capacitor Bank 75kg Brand 6.5kWh 1
High Voltage Capacitor Bank 75kg Brand 6.5kWh 2
High Voltage Capacitor Bank 75kg Brand 6.5kWh 1
High Voltage Capacitor Bank 75kg Brand 6.5kWh 2

High Voltage Capacitor Bank 75kg Brand 6.5kWh

Weight:
75kg
Max. Continuous Discharge Current:
200A
Energy storage:
6.5kWh
Discharge Cut-off Voltage:
37Vdc
Dimensions(WxDxH):
940x400x252mm
Inquiry

Company Advantages

· We have an internal process in place to manufacture high voltage capacitor bank.

· The product is safe and durable, can be used for quite a long time.

· It is a leading and driving force in the market.

Product Parameters
General Characteristics
Mechanical Specifications

Part Number

GTEM-48V6500-G

Energy storage

6.5kWh

Nominal Voltage

48Vdc

Nominal Capacity

130Ah

Maximum Charge Voltage

58.8Vdc

Discharge Cut-off Voltage

37Vdc

ESR/AC @1KHz 50% SOC

<15mΩ

Max. Continuous Charge Current

200A

Max. Continuous Discharge Current

200A

Absolute Peak Current 3s

300A

Discharge Temperature

-20℃~+60℃

Charge Temperature

0℃~+55℃

Cooling Method

Natural cooling

Operating Humidity

0~90% RH Non-condensing

Cells Self-discharge Rate

2% per month

Recommended Depth of Discharge

≤90%

Maximum Depth of Discharge

100%

Shell Material

Metal & ABS plastic

Monitoring Data

System voltage,current, temperature,SOC,SOH,cycle,

cell’s voltage

Indicator light display

Capacity %

Environmental Protection

IP65

Storage Conditions

-20℃~+40℃

25% ~ 95%RH

SOC>30%,one full charge needed per two months

Weight

75kg

Dimensions(WxDxH)

940x400x252(mm)

Mount Options

On floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)
1 (10)
2 (9)
2 (9)
3 (7)
3 (7)
4 (7)
4 (7)
5 (8)
5 (8)
6 (11)
6 (11)
7 (6)
7 (6)

Download


Company Features

· is a manufacturer of high voltage capacitor bank established years ago. We have broad backgrounds and extensive experience in this industry.

· Our QC team are very strict to check the quality of high voltage capacitor bank before shipping. We have QC team to help check the details of high voltage capacitor bank. Each part of high voltage capacitor bank will be checked by our professional QC department.

· We are committed to achieving product superiority over their competitors. To achieve this goal, we will rely on rigorous product testing and continuous product improvement.


Product Details

Based on the professionalism of pursuing excellence, we strive for perfection in every detail of the product.

Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
