High Voltage Capacitor Bank 8.5kWh

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-48V8500-G
Energy storage	8.5kWh
Nominal Voltage	48Vdc
Maximum Charge Voltage	58Vdc
Discharge Cut-off Voltage	42Vdc
ESR/AC @1KHz 50% SOC	<15mΩ
Max. Continuous Charge Current	200A
Max. Continuous Discharge Current	200A
Absolute Peak Current 10s	300A
Discharge Temperature	-20℃~+60℃
Charge Temperature	0℃~+55℃
Cooling Method	Natural cooling
Operating Humidity	0~90% RH Non-condensing
Cells Self-discharge Rate	2% per month
Projected Cycle Life ( 25℃)	20,000 times
Recommended Depth of Discharge	≤90%
Maximum Depth of Discharge	100%
Shell Material	Metal & ABS plastic
Monitoring Data	Module voltage,SOC
Indicator light display	Capacity %
Environmental Protection	IP65
Storage Conditions	-20℃~+40℃ 25% ~ 95%RH SOC>30%，one full charge needed per two months

Weight	75kg
Dimensions(WxDxH)	950x400x252(mm)
Mount Options	On floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Advantages

· All indicators and processes of high voltage capacitor bank meet the requirements of national indicators.

· Its quality is effectively ensured by the strict controlling quality check process.

· The product is extensively used in the domestic and foreign market.

Company Features

· a nation-renowned high voltage capacitor bank developer and manufacturer, is known for its strong R&D and manufacturing competence in this field.

· We possess a very large-scale factory with a good production environment, which enables our workers to carry out a wide range of operations in an orderly manner.

· tries to be the most dominant high voltage capacitor bank supplier. Inquire online!

Application of the Product

high voltage capacitor bank of can be used in various scenarios in different fields.

always focuses on meeting customers' needs. We are dedicated to providing customers with comprehensive and quality solutions.
