High Voltage Capacitor Bank Bulk Buy 200A

Max. Continuous Discharge Current:
200A
Max. Continuous Charge Current:
200A
Energy storage:
10kWh
Discharge Cut-off Voltage:
40Vdc
Dimensions(WxDxH):
865x355x260mm
Inquiry

Product details of the high voltage capacitor bank


Product Introduction

high voltage capacitor bank is one key factor that makes warmly welcomed. The product excels in meeting and exceeding quality standards. The product finds a wide application in the market.

Product Parameters
General Characteristics
Mechanical Specifications

Part Number

GTEM-48V10k-B

Energy storage

10kWh

Nominal Voltage

51.8Vdc

Nominal Capacity

210Ah

Maximum Charge Voltage

58Vdc

Discharge Cut-off Voltage

40Vdc

ESR/AC @1KHz 50% SOC

<15mΩ

Max. Continuous Charge Current

200A

Max. Continuous Discharge Current

200A

Absolute Peak Current 3s

300A

Discharge Temperature

-20℃~+60℃

Charge Temperature

0℃~+55℃

Cooling Method

Natural cooling

Operating Humidity

0~90% RH Non-condensing

Cells Self-discharge Rate

2% per month

Recommended Depth of Discharge

≤90%

Maximum Depth of Discharge

100%

Shell Material

Stainless steel

Monitoring Data

System voltage,current, temperature,SOC,SOH,cycle,

cell’s voltage

Indicator light display

Capacity %

Environmental Protection

IP65

Storage Conditions

-20℃~+40℃

25% ~ 95%RH

SOC>30%,one full charge needed per two months

Weight

82kg

Dimensions(WxDxH)

1124x400x256(mm)

Mount Options

On floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485
