High Voltage Capacitor Bank Manufacture 950x400x252mm

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-48V8500-G
Energy storage	8.5kWh
Nominal Voltage	48Vdc
Maximum Charge Voltage	58Vdc
Discharge Cut-off Voltage	42Vdc
ESR/AC @1KHz 50% SOC	<15mΩ
Max. Continuous Charge Current	200A
Max. Continuous Discharge Current	200A
Absolute Peak Current 10s	300A
Discharge Temperature	-20℃~+60℃
Charge Temperature	0℃~+55℃
Cooling Method	Natural cooling
Operating Humidity	0~90% RH Non-condensing
Cells Self-discharge Rate	2% per month
Projected Cycle Life ( 25℃)	20,000 times
Recommended Depth of Discharge	≤90%
Maximum Depth of Discharge	100%
Shell Material	Metal & ABS plastic
Monitoring Data	Module voltage,SOC
Indicator light display	Capacity %
Environmental Protection	IP65
Storage Conditions	-20℃~+40℃ 25% ~ 95%RH SOC>30%，one full charge needed per two months

Weight	75kg
Dimensions(WxDxH)	950x400x252(mm)
Mount Options	On floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Advantages

· high voltage capacitor bank is well-made all the way around.

· Under the high demand on testing procedure, the product is guaranteed to be zero defect.

· The product can finds application in various industries and will be more widely used in the future.

Company Features

· Since inception, has been actively expanding capabilities for manufacturing high voltage capacitor bank and leads innovative and creative solutions to the changing needs of the industry.

· Our factory has been ISO 9001 certified: an international certification that recognizes the constant improvement of our quality management systems. This allows us to meet the quality requirements of our customers.

· aims to build a safe and economic environment of high voltage capacitor bank industry. Inquire online!

Application of the Product

high voltage capacitor bank can be applied to different fields and scenes, which enables us to meet different requirements.

insists on providing customers with one-stop overall solution from the customer's point of view.
