Company Advantages
· Latest machining techniques are used in manufacturing home energy storage system.
· The overall function of product is unmatched in the industry.
· The effective management and inspection of production process enable home energy storage system produce with high quality.
Part Number |
GTEM-700V25k-R |
Energy storage |
25.3kWh |
Nominal Voltage |
702Vdc |
Maximum Charge Voltage |
83.16Vdc |
Discharge Cut-off Voltage |
554.4Vdc |
ESR/AC @1KHz 50% SOC |
<100mΩ |
Max. Continuous Charge Current |
50A |
Max. Continuous Discharge Current |
100A |
Discharge rate |
2.77C |
Max. Continuous Output Power |
70kW |
Charge Temperature*1 |
0℃~+55℃ |
Discharge Temperature*2 |
-30℃~+60℃ |
Operating Humidity |
0~90% RH Non-condensing |
Cells Self-discharge Rate |
2% per month |
Projected Cycle Life ( 25℃) |
20,000 times |
Recommended Depth of Discharge |
≤ 90% |
Maximum Depth of Discharge |
100% |
Monitoring Data |
System voltage,current, temperature,SOC,SOH,cycle,cell’s voltage |
Terminal |
Large power energy storage terminals |
Environmental Protection |
Indoor |
Cooling Method |
Natural cooling |
Shell Material |
Metal |
Weight |
420kg |
Dimensions(WxDxH) |
560x732x1600(mm) |
Mount Options |
On floor |
Compatible Protocol: CAN, RS485
Company Features
· As a top supplier of high-quality home energy storage system, is internationally renowned.
· spends lots of money on advanced home energy storage system manufacturing facilities. owns modernized workshops, logistics and warehouses. Precision instruments for home energy storage system are equipped by
· We have been contributing to the healthy development of the home energy storage system industry and communities. We never stop creating economic values to support the development of local communities.
Product Details
home energy storage system's details are presented below. They help better know the product.
